Hwacheon Lathe HL 950

The Hwacheon lathe is distinguished from its counterparts for the pure reason that it is a conventional lathe, that is built using high precision technology in mind. This makes the Hwacheon CNC lathe, one of the best lathes in the market. If you require a Hwacheon lathe, then reach out to us today, and we’ll help you find the right lathe for your requirements.

High Quality Precision Universal Lathe

High Precision Conventional Lathe
HL 950 is equipped with a jog switch on the head stock. heavy duty spindle bearing, and the wide guiding surface – prefect for any application where it the key.

ITEM
Unit
HL 950
Swing Over Bed
mm
Ø950
Distance Between Centers
mm
3,000/4,000/5,000/6,000
Swing Over Cross Slide
mm
Ø630
Type of Spindle Nose
KS
A2-11"
Spindle Speed
rpm
850
Spindle Taper of Center
M. T
No.6
Taper of Spindle Bore
M. T
No.120
Through Spindle Hole Diameter
mm
Ø105
Quill Taper
M. T
No.6
Spindle Motor
kW
15
Electrical Power Supply
kVA
29
