Ingersoll Rand 2545X10A 35.5cfm 125psi 10hp Reciprocating Air Compressor

Detachable Base Plate Compressor

This Type 30 compressor 2545X10A has been designed to operate in extreme duty applications and is pressure-lubricated.

The 2545X10A can operate up to 125 psig in remote locations or in off-level operations; it is a true industrial use compressor.

Technical Specifications
Phases 3
Type Base Plate Module
Pump 2-Stage
Capacity 35.5cfm (997 l/min)
CFM Range 35.5
Drive Belt Drive
Motor 7.5kw / 10hp
Voltage 415 Volt
Rated Pressure 8.8 Barg / 125 psig
Weight approx. shipping weight: 215kg
Dimension Pack Dimensions -LWH: 1400mm x 1030mm x 860mm

FEATURES
Cost-effective choice for all Industrial Applications: offering maximum operating pressure, increased air flow and extended duty cycles, the IR Type 30 has been designed for the increasing demands of the industrial market.
Innovative lubricants: have been developed to reduce unwanted oil and prevent carbon build-up and to extend the life between oil changes.
Centrifugal Unloader: Prevents no load starts for maximum starter protection, saving motor life from burning out.
Efficient finned intercooler tubes: By running cooler, it allows the compressor to consume less power and run more efficiently in the most demanding applications.
Two Stage Design: Keeps air pressure temperature down and reduces the power used to deliver pressures up to 175psi
High efficiency stainless steel valves: Cool running valves are heat treated ensuring reduced heat and carbon increase

Why Buy an Ingersoll Rand Type 30 (T30) Compressor?

Leading Engineering
Ingersoll Rand’s renowned Type 30 air compressors have been providing unbeaten performance in the most demanding applications. The Type 30 compressors are recognized as the industry’s benchmark for quality, power and reliability – that’s why they remain the world’s best-selling reciprocating compressor.

Two-Stage Design
The Type 30 air compressor is a two-stage design; this keeps the air temperature down and reduces the power used. There is a Type-30 to meet your needs, whether you work in a demanding industrial environment, automotive repair or repair workshop or a regular business owner.

Full Warranty Protection
Ingersoll Rand is so confident in the performance and durability of their products that each unit is backed by a full manufactures 12 month warranty.

Aftermarket Service and Spare Parts Support
If your air compressor requires servicing, CAPS nationwide service network is only a phone call away. CAPS expert technicians can keep your compressor running in peak condition, potentially saving you thousands of dollars in replacement or breakdown costs. CAPS also stock all the genuine Ingersoll Rand Type 30 compressor parts you’ll need at out dedicated spare parts e-store . Buy service kits online now and enjoy prices 10% cheaper that the RRP.


CAPS Australia offer a wide range of air compressors, power generators & tools. Available all around Australia, with 9 branches located nationwide.

Engineered around your needs, all of our compressors & power generators are built tough for Australian conditions and are backed by our 24/7 service guarantee. Whatever you need, we've got you covered, easy access to over 35 years of local hands-on technical expertise, global capabilities and our renowned aftermarket service programs.

CAPS Australia is proudly 100% Australian owned.

Our Range:
Our precision engineered, European-designed compressor range includes:
• Ingersoll Rand reciprocating, rotary screw and centrifugal air compressors (4.6 – 28200 cfm)
• Airman portable diesel air compressors (55 - 1800 cfm)
• CAPS reciprocating & rotary screw air compressors (6.3 – 1910 cfm)
• Oil free air compressors (27 – 28200 cfm)
• Kohler & Airman Power Generators (10.5 - 4200 kVA)
• Ingersoll Rand & CAPS Tools
• Air Treatment Equipment & Accessories

Our service solutions include:
• Servicing (Compressors and Power Generators)
• Extensive spare parts
• Compressed air audits
• Installation and commissioning

Custom Solutions
CAPS has its own ISO9001 certified manufacturing facility that can modify a compressor to suit your needs. Even the toughest Mine Site specifications can be met.

Your local team of experts will guide and assist you in choosing the right equipment for the job. Call us today!
