JTECH - New Pearson 3200 x 125 Tonne NC Hydraulic Pressbrake

New Pearson NC Hydraulic Press Brake
Capacity: 3200 mm x 125 Tonnes
Robust design with up to 4 axis control for increased productivity & versatility
With fast and precise automatic X & R axis back-gauge
With automatic motorised crowning system
Euro style tooling & quick release top tool clamps
Light curtain guards or Laser guards
Commissioning & training Australia wide from a service team that have a genuine interest in your success

One New Pearson NC Hydraulic Pressbrake
Capacity: 3200 mm x 125 Tonnes

• Twin cylinder down-stroking
• Motorised Y Axis mechanical depth stops within the cylinders with programmable control and
display (via Estun E300 NC Controller)
• Mechanical Ram parallelism via heavy duty solid anti torsion bar
• Adjustable fast approach / working speed change over point
• Adjustable open day light
• Tonnage regulator with pressure gauge
• Motorised X & R Axis back gauge with recirculating ball screws to 600 mm, with programmable control
and display (via Estun E300 NC Controller) complete with three heavy-duty flip type gauge fingers.
• Motorised crowning system in lower table
• 2 x 500 mm front support arms
• Euro style adjustable top tool holders & a set of euro style top tools
• Full length multi vee die or euro style dies
• Full tank of hydraulic oil
• Operation & technical manual
• Machine guarding: Vertical light curtains mounted upon powder coated hinged side fences plus
rear interlocked gate.


OUR SERVICES

• New and Used machinery sales

• Machine Installation and relocation

• Servicing and preventative maintenance

• Machine breakdown support

• Operator and software training

• Consumables and Spare parts


COMPANY BACKGROUND

J Tech Lasers and Sheetmetal Machinery Solutions have joined forces to bring you the very best in the laser and sheetmetal industry.
With over a combined 40 years of experience, this Australian owned and operated alliance will deliver exceptional servicing at competitive prices. We specialise in machine servicing, technical support and breakdowns on all brands of Laser Cutting Machines, CNC Plasma Cutting Machines, Pressbrakes and Guillotine Shears
Preventative servicing measures result in better quality running of your machines and reduces the need for breakdown servicing meaningless machine downtime and loss of production. We provide spare parts for a wide range of machines including tooling for press brakes.
As an independent machinery business we have a genuine desire to see best operating outcomes for our clients and we are also able to source your new machine whether you are looking to either replace or update your current one.
We can provide you with a quote within 1-2 days and with our expert advice ensure you get the machine that best suits your company’s needs and budget.

Go to the J Tech Lasers showroom on Machines4u to see the range of machinery that we are carrying and send us a message about the item that you are interested in, or give J Tech Lasers a call, we are happy to answer any of your questions and provide professional advice for your business solutions.

*CLICK ON THE PDF SPEC SHEET FOR MORE DETAILED INFORMATION *
