JUNGHEINRICH EJC 110 Pedestrian stacker

Model: EJC 110
Maximum Load Capacity 1000 kg
Maximum Lift (h3) 4700 mm
Travel Speed 6 km/h
Overall Length 1822 mm
Battery Voltage 24 V

The strength of the EJC series 1 pedestrian stackers lies in transporting over short distances and stacking and retrieving up to 4700 mm high. Due to its narrow width, the EJC can be manoeuvred particularly easily and safely even in confined spaces.



There is also the option to move the truck in crawl speed mode with the tiller in the upright position.



The 3-phase AC drive motor achieves optimum efficiency combined with the electronic controller developed by us. This enables us to achieve outstanding performance with low energy consumption – the best conditions for rapid and efficient goods throughput.



Operators can take advantage of the precise raising and gentle lowering of loads (optional with EJC 110). Gentle stacking of large loads is made possible by the controlled lifting motor and the handy buttons on the tiller arm.



The EJC 110/112 draw their required energy from batteries with capacities of up to 200 Ah. An integrated and moisture/dust-resistant battery charger (optional) allows simple recharging of the battery at any 230 V socket. This charger is also optionally available with a rapid charging function.



Practical storage compartments on the dashboard and on the front of the truck ensure that all the tools and equipment you may need, such as pens, knives or documents, are within easy reach.
