JUNGHEINRICH EKX 410 Electric Order Picker/Tri-lateral Stacker

Model: EKX 410
Maximum Load Capacity: 1000 kg
Maximum Lift (h3) 8500 mm
Travel Speed 10,5 km/h
Overall Length 3665 mm
Battery Voltage 48 V

Electric order picker/tri-lateral stacker

Our EKX has been the industry benchmark for years.

The Series 4 with a 48-V synchronous drive is ideally suited for the medium lift segment, while the Series 5 – equipped with an 80-V synchronous drive – guarantees maximum performance with lift heights up to 17.5 metres.



The maintenance-free synchronous reluctance motors offer you completely new performance dimensions, and reduce the energy loss by up to a further 10%. Due to its low energy consumption, the EKX can operate for two shifts without a battery exchange, even in demanding applications. This enables the EKX to achieve greater throughput per hour and longer operating times.



In addition, the EKX 5 has the innovative vibration damping system. This offers more safety and performance – even on uneven surfaces.

The future-oriented RFID tracking increases flexibility and adapts travel speeds optimally to your warehouse topology. This makes the EKX a reliable partner for manual, semi-automated or fully automated applications. Our warehouseNAVIGATION also prevents stacking errors and increases throughput by up to 25%. The system is flexible and can be adapted to future requirements. With modular performance and assistance packages, the truck characteristics can be optimally adapted to a wide variety of applications at any time.



The new sideshiftPLUS system also gives you more options for handling different pallet sizes. The EKX has no problem handling different pallet sizes. The increase in basic rated capacity by up to 200 kg makes the EKX even more powerful than its predecessor.



The Series 5 EKX is also available as a fully automated truck.
