KAISHAN -KRSP2-160-8 2-Stage Rotary Screw Compressor

Kaishan Australia reduces your energy expenses by up to 50%.

Kaishan’s ground-breaking world class range of krsp series 2-Stage rotary screw air compressors offers outstanding energy savings when compared to conventional single-stage compressors. They offer unmatched performance, efficiency and reliability for any compressed air reliant industry.

Unlike a conventional single stage compressor, a 2-stage air compressor divides the overall compression ratio between two distinct rotary screw airends. This has the effect of significantly reducing internal leakage losses resulting in substantial efficiency gains as well as extending bearing life due to reduced applied loads.

Kaishan 2-stage air compressors require a smaller drive motor to produce the equivalent volume flow rate to that of a comparable single stage compressor.

Variable Speed Drive VSD is optional with our entire krsp range of single and 2-stage air compressors.
With the elimination of wasted energy, additional cost savings as high as 50% are possible.
In many instances savings mean the additional capital cost of the variable speed drive option can be recovered in less than one years operation.

KRSP
CAPACITY - 33.62M3/MIN
MOTOR SPEED - 1500 RPM
POWER - 160KW
FULL LOAD - 8 BAR
CONNECTION - DN100
DIMENSIONS - 3560 X1910 X 2320
WEIGHT-4900KG

-Upto 20% higher energy savings
-Even more with Variable Speed drive
-Extended bearing life
-Direct Drive, no gears
- Low pressure
-Multiple machine sequencing
-IP55MEPS compliant WEG drive motor

Replacing a single stage with Kaishan 2-stage air compressor technology will typically result in a very rapid investment payback based on energy cost savings. As energy costs continue to rise, these savings will increase. A conservative 17.5% power saving based on replacing a conventional 160kW compressor with a 2-stage unit could realise annual energy savings well in excess of $40,000 based on 8760 operating hours and $0.20/kWhr.

LIFETIME WARRANTY ON ROTARY SCREW AIRENDS FOR KRSP AND KRSP2 COMPRESSORS

Kaishan Australia is absolutely confident in the quality, performance and reliability of these flagship air compressors that we offer an exclusive lifetime warranty on the airends.

12 MONTH WARRANTY FOR ALL KAISHAN COMPRESSOR PRODUCTS - UP TO 10 YEAR EXTENDED WARRANTIES AVAILABLE


Kaishan Australia, a distinguished manufacturer in the Compressed Air sector, has solidified its position as a premier brand, delivering cutting-edge energy-saving solutions to various industries Australia wide. With a robust lineup of high-performance, energy-efficient compressors and system components, Kaishan cater to diverse industry requirements, spanning from small-scale workshops to large industrial applications. Leveraging our global expertise, Kaishan Australia provides tailored industrial air compressor solutions, backed by over six decades of innovation and engineering excellence.

Go to the Kaishan Australia showroom to see the range of machinery, send Kaishan Australia a message about the item you are interested in, or give us a call, we are happy to answer any of your questions.

* CLICK ON THE PDF SPEC SHEET FOR MORE DETAILED INFORMATION *
