KLEEN -Double-head CNC round flange punch machine

After setting the round flange diameter,servo motor drive position machine automatically locate base on different flange diameter.
Manual input diameter and quantity of holes on control panel,indexing plate utilize servo locate, locate tolerance at +0.1mm. Servo motor
will rotate while clamping the part.
Round flange machining diameter range 0300- 2000mm.
Punching mould utilize modular design, it's easy and convenience to change while using it.
Indexing plate clamping unit complete by servo motor with ball screw.
Supporting frame has 6 position so that it can force on workpiece equally, and clamp workpiece stability. The die material is H13K, the
hardness can reach HRC60 and it has great toughness.

KLEEN, a prominent Australian Electro Hydraulic Metalworking machinery designer and manufacturer, proudly represents the Formtek Group product range exclusively in Australia. Our inventory includes renowned HVAC machinery brands like Lockformer, Engel, Iowa Precision, and Formtek from Beijing. Additionally, we offer a diverse selection of fully reconditioned, high-quality secondhand equipment. Our corporate services encompass purchasing used machinery, entire plant acquisitions, auction preparation, consulting, project management, engineering trade labor hire, business and financial consulting, and comprehensive services for insurance, finance, and presale evaluations.
