Kubota Generator 20KVA 3 Phase- SQ-3200B-AU-B

Kubota’s largest and premium generator range, the SQ Series heavy duty four pole diesel generators are incredibly powerful and reliable, yet remarkably quiet. The special enclosure with noise absorbing duct, oversized muffler, extra long air cleaner hose and quieter cooling fan combine for super quiet performance.

Kubota SQ-3200B-AU-B Generator Key Features
The Kubota SQ-3200B-AU-B is a premium compact, three phase four pole diesel generator with a capacity of 20kVA at 1500RPM. Fully sound attenuated for a super quiet operation.

Brushless, self-exciting type alternator delivers reliable, high-quality power.
Sound levels at full load and no load are minimised due to the quieter cooling fans, oversized muffler and noise absorbing ducts within the cabinets.
Centre lifting lugs and fork lift slots ensure easy transportation.
Single sided access for quick inspection and easy maintenance.
Standard with manual key start and hard wire connection to output circuit breaker.
Generator Specifications
Rated Output: (PRIME): 20KVA
Model: V2203
Voltage: 415 V
Amps: 27.8
Power factor: 1
Class of rating: CONTINUOUS
Alternator: BRUSHLESS (WITH AVR)
No of phase: 3-PHASE
Make and model: KUBOTA SQ-3200B-AU-B
Type: Vertical, Water Cooled
Total displacement: 2.197
Rated output: 16.0 KW
Speed: 1500 RPM
Fuel tank capacity: 62 L
Fuel consumption 75% Load: 4.0 L/H
Continuous 75% Load:15.5 H
Overall length: 1675MM
Overall Width: 780MM
Overall height: 970MM
Dry weight: 730KG
Sound levels 7M: 61 dB
Recommended oil; 15W40
Options

The following options can be added to the Kubota range of generators by Blue Diamond.

Mine Spec: Heavy Duty Bunded Skid $1000 - $2500 (24H capacity can be added)
Mine Spec: Battery Isolator $400
Mine Spec: Fire Extinguisher $400
Mine Spec: Protective Frame: $1200
Mine Spec: Water Proof RCD Protection $300
Premium NS70 Battery $212
Warranty

Covered by national warranty, and cover everything for 2 years or 1000 hours. We have service agents Australia wide including Perth, Melbourne, Brisbane, Adelaide, Sydney.

Delivery

We can ship direct to you Australia wide. Alternatively, you can pick up from one of our sales offices located in Perth or Melbourne.



Blue Diamond Machinery is an Australian-owned and operated company specializing in the supply of high-quality power and construction equipment. With a wide range of products including generators, air compressors, lighting towers, and fuel storage solutions, the company caters to industries such as mining, construction, and agriculture. Known for exceptional customer service, Blue Diamond Machinery delivers tailored solutions to meet diverse project needs. With a strong commitment to reliability and performance, the company ensures that every product is backed by expert support, making it a trusted partner for clients across Australia seeking dependable equipment solutions.

Go to the Blue Diamond showroom on Machines4u to see our range, send Blue Diamond a message about the item you are interested in, or give Blue Diamond a call, we are happy to answer any of your questions.

* Click on the PDF spec sheet for more detailed information *
