LEDACRAFT CT-2308 SQUARE CHISEL MORTISER

HOT DEAL : SAVE 880 + GST. WAS $3300 + GST. CURRENT STOCKS ONLY!!

LEDACRAFT MODEL CT-2308 SQUARE CHISEL MORTISING MACHINE

Specifications
§ Cast iron machine on sheet steel cabinet stand.
§ Drill bit held by 16mm drill chuck on motor shaft.
§ Square chisel held by clamping bolt in cast iron head.
§ Complete work head strokes up and down by hand lever with gas strut to assist lifting.
§ Convenient large handwheel for two operations –
1. Lateral movement of work table to centre the mortise.
2. Longitudinal movement of work table when mortising.
§ Cast iron work clamp locks timber onto work table.
§ A depth stop can be pre-set to correct mortise depth.
§ Magnetic switchgear with no-volt release & overload protection.

Technical Data
Capacity of square chisels 6 mm to 25 mm
Maximum stroke of head travel 125 mm
Maximum in & out table adjustment 90 mm
Maximum left to right table stroke 400 mm
Dimensions of cast iron table 513 mm x 167 mm
Single phase electric motor 1.5 hp
Weight of machine 165 kgs
