Model FH50.6
Attachment type 20’/40? Top Pick Spreader
Attachment mounting gantry mount
Capacity on tires kg 40.000
Load centre distance (+/- out/in rach) mm 1.700 (+/- 120)
Load centre to centre of front axle mm 2.616
Lifting height under twist-lock mm 17.900
Stacking Ability – containers 1 over 5 = 6 x 9’6”
Wheelbase mm 6.500
Service weight – unladen kg 76.000
EU Stage 3a Engine make(Rated Power) (kW) CUMMINS QSM11 (250)
EU Stage 4 Engine make(Rated Power) (kW) SCANIA DC13 (257)
Transmission make&model DANA TE32
Service Brakes Wet Disk on front wheels
Tires size 18.00-33
Overall width mm 4.700
Overall length (including spreader) mm 11.460
Overall height (mast lowered) mm 10.600
Seat height mm 2.900
Mast tilt deg 3 / 5
Spreader side-shift mm +300 / -300
Spreader hydraulic (mechanic) pile slope deg 4 / 4
Lift Equipt, a trusted family-owned enterprise with over two decades of experience in materials handling equipment, specializes in forklifts, telehandlers, and access equipment. Our comprehensive services include hire, sales, and maintenance, catering to multiple industry needs. As the premier forklift dealership in Perth and honored as the Hyundai dealership of the year, we offer an extensive inventory of new and pre-owned forklifts, ensuring superior quality and performance.
Committed to excellence, Lift Equipt prioritize customer satisfaction and dependable machinery. Elevate your operations with Lift Equipt, the foremost forklift dealership in Perth, offering a diverse inventory tailored to various needs and budgets.
Go to the Lift Equipt showroom on Machines4u to view the range of machinery, send Lift Equipt a message about the item that you are interested in or give Lift Equipt a call, we are happy to answer any of your questions.
* CLICK ON THE PDF SPEC SHEET FOR MORE INFORMATION *
