LIFT EQUIPT- CVS Ferrari RSE Reach Stacker

EMPTY CONTAINER HANDLING REACH STACKERS

Model: RSE
Attachment Type: 20’/40’ Top Pick Spreader

Performance and Dimensions:
Load Capacity on Tires at 1st/2nd/3rd Row:
1st Row: 12,000 kg
2nd Row: 10,000 kg
3rd Row: 5,000 kg
Load Centre Distance at 1st/2nd/3rd Row:
1st Row: 1,780 mm
2nd Row: 3,850 mm
3rd Row: 6,400 mm
Load Centre to Front Face of the Truck: 735 mm
Lifting Height under Twist-Lock (Hook): 15,875 mm
Stacking Ability (Containers): 1 over 5 = 6 x 8'6":
Service Weight (Unladen): 41,700 kg
EU Stage 3a Engine Make & Model (Rated Power): Cummins QSB6.7 (164 kW)
EU Stage 4 Engine Make & Model (Rated Power): Volvo TAD 871 VE (185 kW)
Make & Model: Dana TE17
Service Brakes: Wet Disc on Front Wheels
Tire Size: 14.00-24
Overall Width (Excluding Spreader): 4,143 mm
Overall Length (Including Spreader): 10,820 mm
Overall Height: 4,275 mm
Seat Height: 2,400 mm
Spreader Rotation (Clockwise/Anticlockwise): -85° / +195°
Spreader Side-Shift (Left/Right): +800 mm / -800 mm
Boom Angle (Min/Max): 0° / 65°

* CLICK ON THE PDF SPEC SHEET FOR MORE INFORMATION *
