HDS 10/20-4 M Force – the powerful, highly efficient three-phase hot water high-pressure cleaner in the Kärcher Middle class. With 4-pole, water-cooled electric motor, two cleaning agent tanks and service electronics.
Economical
In the Eco mode, the unit operates in the most economical temperature range (60°C) with full water flow. Burner cycles are optimised to reduce fuel consumption by up to 20% compared to full-load operation. The stainless steel heating coil offers lasting protection against corrosion and prevents the formation of black water.
Operational reliability
The large, integrated fine-mesh water filter reliably protects the high-pressure pump against the ingress of dirt particles. An integrated exhaust gas thermostat switches off the drive motor if the exhaust gas temperature exceeds 300°C. The soft damping system (SDS) compensates for vibrations and pressure surges in the high-pressure system.
``Jogger`` design with large rubber-tyred wheels and swivel castors.
Integrated tilting aid for effortlessly negotiating obstacles such as steps and kerbs
Technical data
Type of current (Ph/V/Hz) 3 / 420 / 50
Flow rate (l/h) 500 - 1000
Operating pressure (bar/MPa) 30 - 200 / 3 - 20
Temperature (feed 12 °C) (°C) min. 80 - max. 155
Power rating (kW) 7.8
Fuel oil consumption, full load (kg/h) 6.4
Power cord (m) 5
Fuel tank (l) 25
Weight (with accessories) (kg) 159.1
Weight incl. packaging (kg) 171.1
Dimensions (L x W x H) (mm) 1330 x 750 x 1060
Model: HDS 10/20-4 M
Serial: 10221
Article Number: 1.071-903.0
2017 model
Serviced and ready for work
