Inclusions:
• Working Area: 1300 x 2500 x 300mm
• Acceptable Material Thickness: 150mm
• Working Table: Vacuum Table
• Vacuum Pump: 7.5 KW Water Vacuum Pump
• Processing Resolution: ±0.1mm
• Re-positioning resolution: ±0.02mm
• Spindle Motor: 7 Spindle motor 9KW HQD Air Cooling Spindle
• Tool Changer: Duel-process Pneumatic Tool Changer
• Spindle Rotating Speed: 24000rpm
• Transmitting System: X\Y axis Rack and Opinion Square guide; Z axis ball screw Square guide
• Driving Motor: 11 Driving motor X/Y/Z 1.5KW Yaskawa Servo Motor & Driver
• Inverter: Fuling 11KW and Control System: LNC-MW2200
• Processing Speed: ?20000mm/min
• Tool Holder: 12Pieces and Voltage: 3 Phase 380V, 50HZ
• Net Weight: 1400KG and Packing Size: 3850mm x 2280mm x 2050mm
Why Buy Our ATC Router?
• Australian Local Support
• Only the best quality parts used
• Engineers with over 15 years of experience
• Custom built to your specifications
• 3-year Australian warranty – Only if installation package is chosen
