The ECH10.6DS Empty Container Handling Lift Truck offers powerful performance with a 10,000 kg capacity, efficient stacking, and advanced engine options. Perfect for managing heavy containers in ports and yards.
Model: ECH10.6DS
Attachment Type: 20’/40’ Side Pick Spreader – Double Stack Type
Capacity on Tires: 10,000 kg
Load Centre Distance: 1200 mm
Load Centre to Centre of Front Axle: 2425 mm
Lifting Height Under Twist-Lock (Hook): 850 mm
Stacking Ability (Containers): 2 over 5 = 7 x 8’6”
Wheelbase: 4750 mm
Service Weight (Unladen): 39,000 kg
Engine:
EU Stage 3a: CUMMINS QSB6.7 (164 kW)
EU Stage 4: VOLVO TAD 871 VE (185 kW)
Transmission: DANA TE17
Service Brakes: Wet Disk on Front Wheels
Tire Size: 14.00-24
Dimensions:
Overall Width (Excluding Spreader): 4143 mm
Overall Length (Including Spreader): 6860 mm
Overall Height (Mast Lowered): 13,900 mm
Seat Height: 3040 mm
Mast Tilt (Forward/Backward): 3° / 5°
Spreader Side-Shift: +600 mm / -600 mm
Spreader Hydraulic (Degrees): 3° / 3°
Lift Equipt, a trusted family-owned enterprise with over two decades of experience in materials handling equipment, specializes in forklifts, telehandlers, and access equipment. Our comprehensive services include hire, sales, and maintenance, catering to multiple industry needs. As the premier forklift dealership in Perth and honored as the Hyundai dealership of the year, we offer an extensive inventory of new and pre-owned forklifts, ensuring superior quality and performance.
Committed to excellence, Lift Equipt prioritize customer satisfaction and dependable machinery. Elevate your operations with Lift Equipt, the foremost forklift dealership in Perth, offering a diverse inventory tailored to various needs and budgets.
Go to the Lift Equipt showroom on Machines4u to view the range of machinery, send Lift Equipt a message about the item that you are interested in or give Lift Equipt a call, we are happy to answer any of your questions.
* CLICK ON THE PDF SPEC SHEET FOR MORE INFORMATION *
