'Proudly representing Kobelco in North East Victoria and Southern NSW'
Powerful travel, digging, greater swing power and shorter cycle times.
Amazing productivity with 15-21% decrease in fuel consumption and "top-class" cost performance.
2YR/3,000HR Full Machine Warranty and 4YR/6,000HR Major Component Extended Warranty.
Compact design means operators require less than 4 metres of working space.
Light lever operation means less operator fatigue over long hours of operation.
Excellent visibility to minimise blind spots for greater onsite safety.
Includes Kobelco Geoscan Excavator Remote Monitoring System and Kobelco’s exclusive iNDr Cooling System for ultimate low noise and dust reduction.
Rugged durability that ensures long-term machine value.
SPECIFICATIONS
Transport Dimensions
Length, Width & Height
8.83 x 2.99 x 3.13 m
Operating Weight
22,900 kg
Refilling Capacities
Fuel Tank
300 L
Hydraulic Oil Tank
114 (230) L
Working Range
Max. Digging Depth
6.59 m
Max. Digging Reach
9.71 m
Engine
Rated Power Output
118 kW
Rated Torque
572 Nm
Breakout Force
Bucket Digging Force
132 kN
Arm Crowding Force
96.8 kN
Hydraulic System
Max. Pump Flow
2 x 220 + 20 L/min
Standard Auxiliary
