MINI EXCAVATORS SK17SR

'Proudly representing Kobelco in North East Victoria and Southern NSW'

Plenty of working ranges, including top-class max. digging reach and max. digging depth.
Boosted swing power and a top-class swing speed deliver shorter cycle times for greater efficiency and productivity.
Like all Kobelco mini excavators, the SK17SR comes with a standard 4 year/4,000 hour Full Machine Warranty.

The SK17SR has the durability needed in a machine that works in tight spaces. Mini excavators are widely used on sites where space is restricted, such as in residential areas and industrial premises. Users want big power in a small machine, stability in operation, and rugged construction and durability to reduce downtime. The SK17SR combines a compact design with wide digging reach for efficient performance, excellent manoeuvrability, and tough durability to ensure an extended working life.

The swing boom with side-ditch digging function and zero tailswing radius makes it easy to dig next to walls. Crawlers can be easily extended and retracted by operating a simple lever (950mm retracted and 1,280mm extended). The working range of the undercarriage is the greatest in the 1.7 tonne class. The dozer blade with pin-type hinge can be easily extended/retracted for transport.

The four post canopy meets ROPS and FOPS standards for greater operator safety. With a broader floor space, operators have plenty of foot room. Wide operational space is provided with more room between the left and right control consoles, with a comfortable seat. Easier maintenance, with a fully-opening engine hood and equipment that requires the most frequent checks positioned to be readily visible.

SPECIFICATIONS
Transport Dimensions
Length, Width & Height

3.45 x 1.28 x 2.3 m

Operating Weight

1,740 kg

Refilling Capacities
Fuel Tank

20 L

Hydraulic Oil Tank

16.5 (26) L

Working Range
Max. Digging Depth

2.2 m

Max. Digging Reach

3.81 m

Engine
Rated Power Output

10.1 kW

Rated Torque

49.9 Nm

Breakout Force
Bucket Digging Force

15.2 kN

Arm Crowding Force

8.5 kN

Hydraulic System
Max. Pump Flow

2 x 17.6 + 13.2 L/min

Standard Auxiliary

N&B Piping
