Mining Belt Feed Hopper | up to 300TPH | 2m Wide |

The BFH560 can accept up to 300tph at a maximum feed lump size of 150mm material.

The BFH560 is supported on a heavy-duty support structure and has easily accessible inspection doors for ease of maintenance.

Technical Specifications:
- Approximately 7m³ hopper capacity
- 650mm wide variable speed belt feeder
- Easy access grease points
- Throughput between 50-300tph (material dependent)
- Maximum 150mm feed size
- 3kW motor

Dimensions:
- 2200mm wide x 3900mm long x 3000mm high

Options:
- Low friction liners
- Brinell high wear liners
- 500mm extensions to increase hopper capacity to 10m³

Exclusions: Freight, Installation, Electrical works
