Mining Belt Feed Hopper | up to 500TPH | 2.5m Wide |

The BFH1000 is the larger version of the popular BFH560 and is also a skid mounted primary loading belt feed hopper.

The surge hopper is the most sensible solution to ensuring a regulated feed into a processing plant. This skid mounted solution does not require any civils, simply a level compact surface for installation.

The BFH1000 is fitted with a surge hopper and a variable speed conveyor belt. It is designed to be loaded by front end loaders or excavators; and it provides a surge capacity and gives a controlled feed output discharge height ideally suited for the Pilot Crushtec MC750 conveyor belt.


Technical Specifications:
- Approximately 4.6m³ hopper capacity
- Approximately 8m³ surge capacity
- 1050mm wide variable speed belt feeder
- Easy access grease points
- Throughput up to 500tph (material dependent)
- Maximum 300mm feed size
- 15kW motor

Dimensions:
- 2550mm wide x 5900mm long x 3400mm high

Options:
- 500mm extensions to increase hopper capacity

Exclusions: Freight, Installation, Electrical works
