New Sany Sy16C excavator

1.8T Mini Excavator Package
+ SY16C Canopy Excavator
+ Manual Hitch
+ 300mm GP Bucket
+ 450mm GP Bucket
+ 1m Mud Bucket

With an upper width of only 980 mm, the SANY SY16C can easily drive through narrow passages and spaces, especially with the 1825kg weight, making the transportation more easily between different sites. The short tail swing is also ideal for tight job sites and confined spaces

ENGINE
Displacement 0.993L
Engine model Yanmar Tier 5
Rated power 14.6kW/2400rpm

OPERATION RANGE
Height at min. swing radius 2745mm
Max. depth of blade down 320mm
Max. digging depth 2360mm
Max. digging height 3665mm
Max. digging reach 4000mm
Max. dumping height 2635 mm
Max. excavating distance 4000mm
Max. ground clearance of blade up 310mm
Max. vertical digging depth 2215mm
Min. swing radius 1655mm
Operating weight 1825kg

DIMENSIONS
Blade height 270mm
Cab height 470mm
Min. ground clearance 180mm
Tail swing radius 920mm
Track length 1585mm
Transport height 2420m
Transport length 3575mm
Transport width 980/1350mm
Upper width 980mm

UNDERCARRIAGE/WORKING DEVICE
Arm length 1130mm
Boom length 1810mm
Bucket capacity 0.04m³
Roller gauge 1220mm
Track gauge 750/1120mm
Track width 230mm

PERFORMANCE
Arm digging force 9.2 kN
Bucket digging force 15.2 kN
Cooling system 3.8L
Engine oil 2.0L
Fuel tank capacity 23L
Gradeability 30°
Ground pressure 29.1 kPa
Hydraulic tank capacity 21
Swing speed 10rpm
Travel speed 3.7/2.1 km/
HYDRAULIC SYSTEM
Hydraulic motors - swing 10rpm
Hydraulic motors - travel 2.1/3.7km/h
Main pump - maximum flow 48lpm
