Overband Magnet | With Support Frame | Self Cleaning |

The MPM910 self-cleaning permanent overband magnet is designed to offer an economical ferrous removal solution. The self-cleaning belt is electrically driven.

This magnet can be used to effectively remove ferrous materials from conveyors prior to being fed into crushing units to protect crushers from receiving uncrushable items.

The frame is designed to cater for a conveyor which can slew radially when servicing a crusher.

Technical Specifications:
- Effective range between 0-400mm
- Magnetic force between 1450-280cgs
- Operating speed of 1.7m/s
- 2.2kW motor

Options:
- Removal of support frame

Dimensions:
- 1920mm wide x 2300mm long x 4080mm high (adjustable)


Exclusions: Freight, Installation, Electrical works
