CNC Cutting and Drilling
Tried and True Heavy Duty Drilling
The PCS EHD CNC cutting and drilling machine was first introduced in 1996 and is based on the legendary HD series. The EHD has a triple-supporting main beam and uprated structure throughout. The EHD CNC plasma cutting and drilling machine is recommended in favour of the HD for spans over 5m and/or if Heavy-Duty Drilling is required. Like the HD series, the EHD is known for its reliability and longevity and is available in multiple configurations with options ranging from Plasma Bevelling, Oxy/Fuel Bevelling, Drilling, Tapping, Machining, Pipe Cutting, Pin Marking, Paint-Jet Marking and much more.
PCS MHB at a glance:
Cutting Width up to 8m (~26f)
Multiple Cutting Operations – Plasma up to 800amps, Plasma Bevel, Flame, Flame Bevel
Optional 14HP BT-40 Drill Head for high speed drilling of holes up to 40mm dia.
Excellent reliability and longevity thanks to Extra Heavy Duty construction and quality components
Class Leading Burny 10 PC based CNC on custom PCS flat panel touch screen (up to 21.5”)
Manufactured from NON-PROPRIETRY components
State-Of-The-Art Motion Control System – Bosch Rexroth digital drives and motors with absolute encoders
25m/min traverse speed (limited)
Heavy Duty floor mounted rail system made of machined hardened billet
Automatic rail cleaning/polishing system. Cleans and polishes running surface as machine traverses
OPTIONAL HEADS:
Hypertherm XPR300/XPR170 Plasma
Lincoln Electric FineLine 300 Plasma
PCS Zero-Offset Plasma Bevel Head
Oxy Fuel cutting head
PCS Triple Burner OxyFuel Bevel Head
Pin Marking
Drilling Head – 3 axis BT-40, 14HP, 40mm Drilling capacity
For more information, visit .profilecuttingsystems
