PEERLESS PHP15 Truckies Series Belt Drive Skid Foot Tank Petrol Air Compressor

The PHP15 is a 6HP Honda engine high pressure compressor capable of running at 175PSI. These machines are fantastic for tyre inflation i.e.. truck tyres or applications where large volumes of air at high pressure is required. The advantages of a two stage compressor is that you do not lose volume of air at higher pressure. The air temperature is some 40% cooler than the standard type of air compressor therefore producing less condensation. Electric start optional extra. Please call Peerless for a quote.

Twin Tank The twin tank model is designed for better portability and stability in the back of vehicles. It's low center of gravity ensures stability in the back of utilities and on uneven ground The handle is also removeable making it a very compact unit when needed.

Ute Mate The Peerless “Ute Mate” Honda powered compressor is the perfect answer to your utility vehicle needs. The model features huge power all contained in a modestly sized roll cage in order to keep your work horse in top shape, no matter the conditions!

2" Tube Tank With the performance of the 2" tube tank there is no down time on waiting for a receiver to fill, just instant pressure. If you lose pressure just take your finger off the trigger and then you’re back to full pressure again in less than 2 seconds. Being such a unique design, this frees up valuable space on or in the service truck/van which can help with any space or weight issues you may currently have.

Under / Over The under & over model is extremely popular for saving space in the back of service vehicles or trailers. The greatest advantage of these and the tube models is their quick recovery time within 6 seconds you are back to full pressure and there is not much sense in pumping up a large air receiver before you pump up your tyres.

Electric start engine does not come with battery, leads or provisions for battery. We can manufacture to your design plus there are other standard designs for each model.

Performance of all our belt driven air compressors are to AS4637.

Code : 00101-SF
Model : Skid Foot
Pump Displacement (CFM) : 15 CFM
Free Air Delivery (LPM) : 320 LPM
Max PSI : 175
Engine : Honda GX200
Warranty Pump : 5 Year
Warranty Engine : 3 Year
Tank Capacity (L) : 68L
Pump up time to 100PSI : 1.25 - 1.30 Min.
Dimensions (mm) / Weight (kg) : LxWxH kg
Cooling Method : Air cooled
Pump Type : 2065T 2 Stage
Cylinders : 3
Pump Head Tension : 12 FT LB 16.27NM
Oil Capacity : 1.375L
Pump RPM : 1236
Outlet Thread : 1/4" BSP
Engine Fuel Capacity : 3.1L
Engine Oil Capacity : 600ml 10W/30
