PVE 7/9NL Impact Hammer and Power Pack - Configurable with 7 or 9 Tonne Ram Mass - Hire

Ram Mass: 7,000 - 9,000 kg
Energy Transfer: 84 - 106 kNm
Drop Height: 100 - 1,200 mm
Frequency at Max. Stroke: 40 bpm
Total Weight: 12,500 - 16,400 kg

PVE recognizes the importance to adapt to changing circumstances during pile driving operations, especially when it comes to soil. For this reason the PVE hydraulic impact hammers are designed in a modular configuration. For every hammer type it is possible to adjust the impact energy by adjusting the drop height. This can also be accomplished by adding or removing drop weights.

PVE impact hammers are excellent for lots of applications. The most common application is the installation of precast concrete piles. PVE impact hammers are also very suitable for driving steel casing piles, sheet piles and cast-in-situ concrete piles.

PVE drive caps and sleeves are suitable for the following applications:
• Precast concrete piles
• Timber piles
• Steel casing piles
• Steel profiles (H and U beams)
• Steel and concrete sheet piles
• Combined sheet pile walls
• Cast-in-situ concrete piles

Our experts are available to help you find the most suitable impact hammer for your project.
