FEATURES
Quality casting, construction componentry.
Emergency stop.
NVR safety switch.
Each Unit Supplied With:.
Chuck safety guard.
Drill chuck arbor.
Drill drift (on MT models)
SPECIFICATIONS
Drilling Capacity (mm): 16mm (5/8")
Spindle Taper: #2MT
Chuck: 3-16mm B16
Motor Power: 550W 240V
Spindle Travel (mm): 85
Speed: 16 Speed 180-2770
Swing (mm): 325
Table Size / Base Size (mm): 290 / 460x272
Column Diameter (mm): 72
Height (mm): 1580
N.W. / G.W. (kg):50 / 53
Drill press vice to suit: VDP102
Cross slide vice to suit: TM130-100
