Primary Voltage
208-575 Volts
Input Power
Single or Three phase
Open Circuit Voltage
80 Volts
Rated Output
450 Amps 44 Volts 100% duty cycle
Welding Current Range
5 - 600 Amps
Dimensions
H: 1041mm
W: 394mm
D: 559mm
Shipping Weight
72.9 kg
Features
The one-package pipe welding solution for both field and shop fabrication. Multiprocess capabilities include new patented RMD Pro and Pro Pulse which are optimized for steel and stainless steel pipe.
Auto-Line allows for any input voltage hook-up (190–630 V) with no manual linking. Compensates for voltage spikes and drops within the entire range.
Use conventional or advanced MIG (GMAW) processes without making any hardware changes. Just select program and weld.
Wind Tunnel Technology circulates air over components that require cooling, not over electronic circuitry, which reduces contaminants and improves reliability.
Fan-on-Demand cooling system operates only when needed and reduces amount of airborne contaminants pulled through machine.
