Plastic Extrusion Welder 3kg/hr - Ritmo K-SB30 Stargun

The Italian-Made Ritmo K-SB 30 Stargun Extruder is suitable for welding PE, PP and PVDF according to the DVS 2207 standard. This machine is equipped with the power regulation system, the "engine block" safety device that does not allow starting until the operating temperature is reached.

Matrix Piping Systems also offers servicing, calibration and spare parts for Ritmo poly welding machinery. Our experienced team of service technicians can assist you with diagnosing and repairing any issues that may arise. Call us today to find out more!

Machine Composition:

- Illuminated control display
- Two high brightness LEDs for welding area
- Power regulator; "motor lock" safety system
- Autonomous blower
- Thermoregulator with double T ° control: blower / extrusion
- Rotatable handle
- Interchangeable and 360 ° rotatable tip

Technical specifications:

Material: PE / PP / PVDF
Wire: Ø 3 - 4 - 5 mm
Output: up to 2.9 Kg / h with wire Ø 5
dimensions: 500 x 310 x 100 mm
Weight: 7.1 Kg
Voltage: 230 V
Absorbed power: 3350 W
Frequency: 50 Hz
Weldable plates: 1.5-30 mm
