Portable Silent Box Compressor 23 HP 75CFM Rotair DS 22Y

ROTAIR 75 CFM DS 22 Y PORTABLE SILENT BOX DIESEL AIR COMPRESSOR
The new modern and streamlined look of ROTAIR portable compressors with compact dimensions for handling ease, whilst at the same offering high performance levels. Build tough and reliable for the demanding Australian conditions. 50c ambient for extreme operating conditions.

Low-Speed Air-End spins at a maximum of 2600 rpm, reducing heat and virtually eliminating rotor and bearing failures.

Blue Diamond Machinery are an exclusive ROTAIR distributer in Australia.

Compressor Key Benefits
European designed & made to exact international standards
Easy to service and maintain
Industry leading compact box type compressor. Perfect for service vehicles.
Wet weight (includes fuel & other liquids) is 5 kg less than competitor units
Environmental sustainability: Only 75 cfm box unit on the Australian market with a tier 4 engine. This means 90% lower Nox emissions & PM than competitor tier 3 equivalent diesel engines
Best in class fuel efficiency. Use 1 litre less per hr (full load) than like competitor units
Intelligent controller as standard feature
Exclusive pneumatic system that adjusts engine revs to free air demand

COMPRESSOR SPECIFICATIONS
Free Air Delivery (Lt/min)- 2,000
Free Air Delivery (CFM)- 75
Operating Pressure (bar)- 7
Operating Pressure (psi)-102
Transmission Motor-Screw Unit- Direct Drive
Air End Operating Speed (RPM): 2600

ENGINE SPECIFICATIONS
Engine Model: Yanmar 3TNV70-AYE2D
Cylinders: 3
Displacement: 854 cc
Cooling: Liquid
Maximum Speed (rpm): 2700
Maximum Speed (Idle) (rpm): 1600
Air Intake system: 2 - stage dry
Engine HP: 23 HP

GENERAL SPECIFICATIONS & DIMENSIONS
Fuel Tank Capacity: 28 L
Electrical System: 12 Volt
Length (mm): 1400
Width (mm): 750
Height (mm) 862

Warranty
5 Year unlimited Hour Air-End/Drive Coupling Warranty. Diesel Engine 2 year/1000hrs.

Delivery
We can ship direct to you Australia wide. Alternatively, you can pick up from one of our sales offices located in Perth or Melbourne.

AIR COMPRESSOR KEY FEATURES
- “Intelligent System”- enables a pre-heating of the engine without overloading it, the air end will start working only when the perfect conditions are reached.
- Fuel Saving System- when the compressed air is not required, the system allows to compress air at a much lower thus saving fuel consumption significantly. Up to 20% in fuel saving!
- Easy Maintenance- Clean and easy layout for quick and efficient maintenance and control
- Control Board- complete and fully functional using a “NO KEY” system. So that no keys are needed for internal access to the unit and for its ignition.
- Made in Europe- Engineered and manufactured in Europe using top quality materials. Direct coupled, no gearbox

Compressor Servicing
Blue Diamond Machinery also provides comprehensive range of air compressor servicing, preventative maintenance and compressor repair services across Perth, WA. With over 25 years of experience servicing all types of compressors our service team ensure minimum downtime, quality and reliability on all compressor service and repair work.
