2 stage standard mast
Lift Height options
2900mm
3200mm
3600mm
Load capacity: 2000kg
Fork 570*1150 or 685*1150
Battery 24V350AH 45A charger
AC motor with pedal
Electronic steering
3 stage full free mast
Lift Height options
4000mm
4300mm
4600mm
Load capacity: 2000kg
Fork 570*1150 or 685*1150
Battery 24V350AH 45A charger
AC motor with pedal
Electronic steering
• The rated load capacity of XCS-P20 stacker series is 2000kg
• With compact design, short overall length, and small turning radius, it can be used in narrow spaces.
• The full-proportional lifting/ lowering hydraulic system can realize the accurate positioning during the lifting/lowering.
• This machine features high traveling speed and can be installed with diversified optional battery types and lithium batteries to meet more customer needs.
• It can be installed with optional side-pull battery. The all-new patented battery lock mechanism can eliminate the shaking of battery and reduce the noise during operations.
• The optional password lock allows the start of machine by manually inputted password or card swiping.
Options
1. Battery 24V270Ah 35A Charger
2. Change standard 2 stage mast to full free
3. Lithium Battery 24V150Ah 60A charger
