Designed to a Higher Specification with "Mechatronics" - Easy to use and high efficiency!!
Mechatronics Bag Feeding
Mechatronic vibration
Mechatronics seal
Remote maintenance
Allows for easier, quick loading of bags into the conveyor.
- Dramatically reduces bag transfer failures.
- The surface deck area is completely bolt-less feature.
- Significantly improved Hygienic design for cleaning.
- A true 90 seconds product change-over design feature.
- Decreased 10:1 change-over time when compared with other models requiring 30 minutes.
- Automated, Self-Adjusting Bag Tapping Mechanism Feature.
- Three tapping factors : Bottom Tapping time, Frequency and Strength are adjusted automatically.
- Automated Sealing Time, Pressure and Temperature Control.
- Correspond to Traceability.
- In-Line Bag IJO Code-Printing Capabilities Surface Are has Doubled.
- Able to handle various types of Bag Design.
SPECIFICATIONS
Packaging capacity 15 to 65 bags per minute (depending on the product)
Bag dimensions Width: 100 to 230mm,
Length: 130 to 380mm
Filling quantity Maximum: 1 kg (optional : 2kg)
Outline dimensions
(Reference) Width: 1491 mm,
Length: 3250 mm (UST)
