Promag 53 Liquid Flow Meter

Promag 53 Promag H - Item was removed from operating factory.
The flowmeter for smallest flow rates with a modular electronic concept and/ or with flexible system integration.
Application:
• The measuring principle is virtually independent of pressure, density, temperature and viscosity.
• For the smallest flow quantities and demanding hygienic applications.
Make: Endress Hauser
Model: 53H50-1NX5/0
22-55VAC / 16-62VDC
15VA/W 50-60Hz
IP67/NEMA/Type4X
I-OUT (HART), f-OUT

Promag H
K-Factor: 0.7722 /-4 0.2?L
DN50/2inch PN16/230PSIG
Tm: -20 degrees C ...150 degrees C
Materials: PFA EDPM
Electrodes: 1.4435 / 316L
