Genie® Telescopic S™-Booms offer greater horizontal outreach than any other type of aerial platform — perfect for areas with limited access in construction and industrial applications.
If this is not the specific unit to suit your needs, please don't hesitate to contact us anytime to discuss your Access Equipment requirements.
Finance options available!
Features:
• 2.44 m (8 ft) steel platform
• 1.52 m (5 ft) jib boom with 135° working range
• 4WD Positive traction drive
• Full-time active oscillating axle
• Fully proportional controls
• 360° continuous turntable rotation
• Foam-filled Rough Terrain tyres
• Two speed wheel motors
• Closed-loop hydrostatic drive
• Engine protection package
• Auto engine fault shutdown
• Drive enable system
• Wire braided hose
• Hydraulic oil cooler
• Intake air heater
• Self-leveling platform
• Hydraulic platform rotation
• Swing-out engine tray
• Engine gauge package
• Locking turntable covers
• Foot switch time out
• Lockable platform control box covers
• Thumb rocker steer
• Tilt alarm
• Dual flashing beacons
• Electric horn
• Motion alarm
• Hour meter
Specifications:
• Chassis Type 4WD
• Boom Type 1.52 m (5 ft) jib boom with 135°working range
• Hydraulic Fly Boom N/A
• Platform Rotation 160°
• Maximum Working Height(m) 15.72
• Maximum Platform Height(m) 13.72
• Maximum Horizontal Reach(m) 11.18
• Lift Capacity / SWL(kg) 227 kg
• Weight / Outreach Limited No
• Turret Rotation N/A
• Outrigger Stabilisers N/A
• Minimum Transport Length(m) 0.91
• Minimum Transport Width(m) 2.30
• Minimum Transport Height(m) 2.49
• Power Deutz D2011L03i 3 cylinder diesel 34.3 kW (46 hp)
• Weight(kg) 7,151 kg
QLD Access is Australia's longest running Access Equipment company located in Brisbane, and our branches are located in Sydney, Melbourne and Perth.
Operating since 1981. we have the industry knowledge and expertise to look after all aspects of your Access Equipment needs whatever they may be.
We specialise in Equipment Sales, Cross Hire, 10 Year Re-Certification of all Access Equipment, preventative maintenance, scheduled servicing and spare parts.
We offer New/Used & Re-Certified equipment Australia wide from all manufacturers.
With over 250 used Boom lifts and Scissor lifts in stock at any given time and our huge dealer network, we are sure to have your Access needs covered.
Finance options available!
Visit the Queensland Access showroom on Machines4u to see more of our equipment, send us a message about what you are interested in or give Queensland Access a call, we are happy to answer your questions.
* click on the pdf spec sheet for more detailed information *
