Genie Z-40/23N RJ

Genie® DC and Bi-Energy machines offer quiet, emission-free operation in the most sensitive work environments. For industrial applications where the machine must be driven significant distances, the Genie bi-energy system combines the benefits of a 48V DC machine with the versatility of a diesel-powered generator.

The listed price is true and correct as of June 2023.

If this is not the specific unit to suit your needs, please don't hesitate to contact us anytime to discuss your Access Equipment requirements.

Features:
1.17 m (3 ft 10 in) steel platform
1.22 m (4 ft) horizontal rotating jib boom 130° with working range
2WD Electric AC
Solid rubber non-marking
1.50 m (4 ft 11 in) width
0.87 m (2 ft 11 in) inside turning radius
Self-leveling platform
Hydraulic platform rotation
Fully proportional controls
Thumb rocker steer
Drive enable
Horn
Hour meter
Tilt alarm
Alarm package
Hydraulic filter condition monitor
355° non-continuous turntable rotation
Variable speed high efficiency hydraulic power unit
AC electric drive system
Traction control
On-board easy to understand diagonostics
Dual flashing beacons

Specifications;
Chassis Type 2WD Electric AC
Boom Type 1.22 m (4 ft) horizontal rotating jib boom 130° with working range
Hydraulic Fly Boom N/A
Platform Rotation 180°
Maximum Working Height(m) 14.32
Maximum Platform Height(m) 12.32
Maximum Horizontal Reach(m) 6.91
Lift Capacity / SWL(kg) 227 kg
Weight / Outreach Limited No
Turret Rotation N/A
Outrigger Stabilisers N/A
Minimum Transport Length(m) 6.53
Minimum Transport Width(m) 1.50
Minimum Transport Height(m) 1.98
Power 48 V DC (eight 6 V batteries) 350 Ah capacity
Weight(kg) 6,940 kg


QLD Access is Australia's longest running Access Equipment company located in Brisbane, and our branches are located in Sydney, Melbourne and Perth.
Operating since 1981. we have the industry knowledge and expertise to look after all aspects of your Access Equipment needs whatever they may be.
We specialise in Equipment Sales, Cross Hire, 10 Year Re-Certification of all Access Equipment, preventative maintenance, scheduled servicing and spare parts.

We offer New/Used & Re-Certified equipment Australia wide from all manufacturers.
With over 250 used Boom lifts and Scissor lifts in stock at any given time and our huge dealer network, we are sure to have your Access needs covered.

Visit the Queensland Access showroom on Machines4u to see more of our equipment, send us a message about what you are interested in or give Queensland Access a call, we are happy to answer your questions.

* click on the pdf spec sheet for more detailed information *
