FEATURES & BENEFITS
Wide Working Range
High Efficiency
Low Fuel Consumption
Electric Option Available
Proven Reliability
SANY DOMCS Control System
SPECIFICATIONS
POWER & MOVING SYSTEMS
Engine Type ISUZU
Rated Power 212 kW/2000 rpm
Fuel Tank 540L
Drive Four wheel drive/four wheel turning
Axle DANA turning drive axle
Gear Box DANA 2
Tyre 12-24 solid
Hydraulic System Kawasaki positive hydraulic system
CABIN & BOOM
Lifting Structure Single four linkage bar lifting
Lifting Height 2650mm
Boom Spec: K14 K16 K17 K18 K20
Moveable Boom 8.6m 8.6m 9.6m 10.5m 10.5m
Stick 6.0m 7.5m 7.5m 7.5m 9.5m
Working Radius 13.5m 15m 16.5m 16.5m 18m
Working Depth -5m -7m -8.5m -8.5m -11.9m
Working Height 14.5m 15.5m 16.5m 18m 18m
OPERATIONAL SPECS
Gross Weight 45.2 T
Speed 3 km/h (load) /5 km/h (unload)
Gradeability 40%
Rotation Speed 0~8 r/min
