Featuring exceptional compaction performance, the SANY road rollers greatly meet the demands of compaction for asphalt road and cement stabilized base. The advanced hydraulic system offers higher efficiency and more productivity.
HIGH EFFICIENCY
10% greater excitation force than other products in the same category resulting in 16.7% greater production.
EXTENDED LIFE TIME
The use of water wheel type lubrication on the vibratory bearing extends the bearing life up to 5,000 hours.
The engine air filter is raised and the air is filtered twice to protect the engine.
The hydraulic system contains three stage filtration.
OPERATOR COMFORT
Cab mounted on vibration damping mounts
Cab climate control
Operator control forces have been reduced
SAFETY FEATURES
Rounded bumpers front and rear
Large rear glass and sloped hood for greater visibility
ENGINE
Operating Weight 18000 kg
Engine model DONGFENG CUMMINS QSB5.9-C180-33
Rated power 133 kW
DIMENSIONS
Min. Turning Outside Diameter 12350mm
PERFORMANCE
Fuel tank capacity 300L
Gradeability 45%
Hydraulic tank capacity 150L
Travel speed 0 ~ 8km/h
