SHAW - HAFCO Surface Grinder SG-820H

SG-820H SURFACE GRINDER 450 x 220mm

CALL FOR OUR BEST PRICE

The SG-820H is an excellent surface grinder for grinding precision parts in hardened or annealed ferrous metals. It features heavy duty cast iron construction, quiet running precision spindle, ball bearing longitudinal slide, coolant system and more.

Features
Hydraulic longitudinal table travel
Quality castings and Precision Japanese P4 ball bearing supporting the spindle
Coolant system with nozzle and flow control valve
Cast iron machine body and stand for maximum rigidity and smooth operation
Vertical dial graduations 0.01mm
Cross travel graduations 0.02mm
Manual one shot lubrication pump
Wheel balancing stand and arbor
400 x 200mm Magnetic Chuck
450 x 220mm Table Feed
Diamond wheel dresser
Halogen work light
1100W / 1.5hp / 415V motor



Specifications:
MODEL: SG-820H
CODE: G220
Chuck Size: 200 x 400mm
Max. Longitudinal Table Traverse: 450mm
Max. Cross Table Traverse: 220mm
Max. Spindle to Table: 465mm
Wheel Diameter: 200mm
Vertical Graduations: 0.01mm
Vertical Graduations /Rev.: 1.25mm
Motor: 1.1kW / 1.5hp / 415V
Weight (Nett): 795kg

all prices are subject to change and are GST exclusive
