SPL006 Refrigerated Air Dryer - 21 cfm

The SPL006 Refrigerated Air Dryer offers efficient, reliable performance with a 21 cfm (0.6 m³/min) air flow. Designed for up to 16 barg pressure, it ensures dry, clean air, operating in extreme conditions up to 50°C.

Dryer Model: SPL006
Air Flow: 21 cfm (0.6 m³/min)
Power: 0.17 kW
Air Connection: 1/2" BSP
Dimensions: 450 x 430 x 210 mm (W x D x H)
Weight: 19 kg

Performance Specifications:
FAD Conditions: 20°C / 1 bar A
Working Conditions:
Air suction: 25°C / 60% RH
Working pressure: 7 barg
Pressure dew point: According to ISO 8573-1
Cooling air temperature: 25°C
Compressed air inlet temperature: 35°C
Refrigerant: R134a
Maximum Operating Pressure: 16 barg

Operating Conditions:
Ambient temperatures up to 50°C
Inlet temperatures up to 65°C
Standards Compliance: All indicated data is in accordance with DIN ISO 7183.
