General Specifications
Vibratory Force: 45 KN
Engine Power: 28.5 KW
Operating Weight: 3000 KG
Overall Dimensions: 2400 mm x 1300 mm x 2360 mm
Weight: 2200KG
Engine and System
Engine: Changchai 390 National III engine
Drive System: Hydraulic dual drive
Vibration System: Hydraulic vibration
Hydraulic Pump: Danfoss imported variable pump
Hydraulic Motor: Imported Danfoss hydraulic motor
Hydraulic Vibration Pump: Parker
Wheel Width: 1200 mm
Wheel Diameter: 560 mm
