Description: Working width [m /ft]: 2,60 / 87 to 3,40 / 112
Transport width [m /ft]: 2,15 / 71 to 2,20 / 72
Transport hieght [m /ft]: 3,40 / 112 to 4,20 /138
Swath width [m / ft]: 1,20 1,80 / 311 511 to 2,30 2,80 / 77-92
Necessary hydraulic couplers: 1 x single acting
Working capacity [ha/h / ac/h]: ~ 3,00 / ~ 7,40 to ~ 4,00 / ~ 10,00
Number of discs/knives [pcs.]: 6/12 to 8/16
RPM: 540
3-point hitch cat.: II
Power demand [HP]: from 70 to 90
Weight [kg / lbs]: 725/1600 to 825/1820
PTO shaft: tractor mower: with overrunning clutchLinkage mower , HYD fold , 8 Disc-16 quick change blades , 3.4m cut , Perfect CUT cutterbar
Industry: Hay/Forage Equip
