Seppi SMWA s skid steer hydraulic drive mulcher

flail mulcher for PTO/Tractor 30-90 HP

Agriculture or greenspace maintenance easy with the 30-90 HP tractor and the strong flail mower SMWAs. This versatile mulcher is available available in different working widths up 105 [41?] to 200 cm [79?]. Mulching grass, prunings and bushes up to 5 cm [2?] in diameter.
The PTO/Tractor mulcher SMWA s can be shifted to the right up to a maximum of 27 cm [10.6?]. The hyd. side shift is linear and works even while the machine is mowing, with hydraulic control from the tractor seat. The reversibility of this mulcher makes possible to fit the machine on the front or back of tractor.

Helical distributed and high resistent SMW-flails for universal use are for high cutting quality at uniformly distributed power. SMWA s casing is very resistent, made of high-tensile steel. Double counterknives inside the casing will give a perfect result when mulching. Adjustable roller with double tapered roller bearings unit for a long life and the low maintenance costs. Adjustable roller is positioned close to the rotor improves mulching on uneven ground and prevents scalping.

Available working width: 105, 115, 125, 135, 145, 155, 175, 200 cm [41'', 45'', 49'', 53'', 57'', 61'', 69'', 79''].

STANDARD VERSION

Mulches grass and prunings up to 5 cm [2?] Ø
Standard rotor with SMW flails
Working speed 3-10 km/h
Reversible ISO 3-point linkage cat. 1&2
Linear hydraulic side shift 27 cm [10.6?]
540 rpm gearbox with freewheel and through shaft
Input shaft 1 3/8? Z=6
Belts: ? 155: 3 ; ? 175: 4
Adjustable rear hood with rubber protection
Reinforced support roller, adjustable in height by 5 cm [2?]
Front protection: metal flaps
Colour: red RAL 3020

OPTIONS

PTO drive shaft
Rotor with Y knives
1000 rpm or 750 rpm gearbox
Gearbox with automatic inverter and double freewheel for reversible tractors
Front attachment
Front protection with chain
XAN – hyd. sweeper with 3 vanes
XID – herbicide spraying system
