The SW28 brings maximum reach making it ideal for loading and unloading. The SW 28 delivers 2,800 pounds of rated operating capacity at 50% and a lift height up to 134 inches. The machine is equipped with a 74.3 hp turbo-charged Perkins Tier IV Final engine. Available in both H-pattern and ISO joystick pilot controls, the machines can fit the preferences of any user. The ergonomically designed controls and pressurized cab delivers comfort and visibility, reducing operator fatigue, increasing productivity.
Standard two-speed transmission increases travel time on the job sites giving the operator more time throughout the day to get more tasks completed.
Spacious extended cab maximizes room and comfort for the operator to move inside the cab.
Optional high flow hydraulics increase the range of usable attachments improving efficiency and productivity.
Quick and easy service access from the forward tilting cab and the arrangement of internal components makes it easy to maintain the machine.
Hydraulically driven fan operates on an as-needed basis allowing faster warm-up times of the engine and significantly reducing noise.
SW28 Standard components
Vertical Lift Arm
Perkins, 4 stroke, 74.3HP turbo charged diesel engine, Tier 4 Final compliant
12” x 16.5” All-Terrain Tires
Rexroth ® Hydrostatic Pump and drive motor
Available in H-Pattern or ISO Controls joystick pilot controls
2-Speed transmission with top speed of 4.3 mph (low-speed) and 8.7 mph (high-speed)
Spring-applied, hydraulic released wet-disc parking brakes
Hydraulic universal skid steer quick-hitch system for attachments
Front Auxiliary Hydraulics with flat face couplers
Arm Float Position
Adjustable spring suspension comfort seat with seat belt
Foot and Manual Throttle
Front and Rear work lights
ROPS Level I compliant canopy
Lexan Safety Roof
Back up alarm
12-Volt Power Accessory
Seat Belt
Isolated Pressurized Cab*
Automotive style HVAC system*
Easy-to-Access side windows*
Radio-Ready
*Available on Cab units only
SW28 Options:
Hydraulic Coupler
Enclosed Pressurized Cab, Heat, Air Conditioning
Engine Block Heater
One Way Hydraulic Bucket Leveling
Ride Control
Radio
12×16.5? Premium Tires
Adjustable High Flow
14 Pin Front Electric Attachment Control
