Snorkel S9043RT Rough Terrain Scissor Lift

Max. Working Height: 15.1m
Overall Width: 2.28m
Platform Capacity: 680kg
Weight (without outriggers): 7,500kg

The new Snorkel S9043RT high capacity rough terrain scissor lift delivers high performance. Equipped with a spacious roll-out deck, this scissor lift offers excellent lift capacity. Superb terrain capabilities can easily handle tough jobsite conditions on powerful 4-wheel drive.
The S9043RT is packed with operator benefits such as saloon-entry gates and swing-out engine trays.

STANDARD FEATURES
4 wheel drive
Single powered deck extension
Foam filled tires
Proportional controls
Power line to platform
Platform overload system
Drive motion alarm
Descent alarm
Fold-down guardrails
Flashing amber light (x2)
Locking, oscillating axle
Hour meter & on-board diagnostics display
Manual lowering valve
Flashing amber light (x2)
Dual lanyard attachment points
2 years parts & labor, 5 year structural warranty
*whichever comes first. Refer to Snorkel warranty policy for full details, limitations and restrictions. Batteries at the end of their life to be returned to Snorkel for recycling.


Max Working Height
15.1m

Max. Platform Height
13.1m

Platform Size (stowed)
3.58m x 2.28m

Platform Size (single deck extended)
4.95m x 2.28m

Platform Size (dual deck extended)
6.7m x 2.28m

Extension Deck Length
1.44m

Overall Width
2.28m

Overall length (without outriggers)
4.08m

Overall length (with outriggers)
4.77m

Stowed Height
2.99m

Min Height (guardrails folded)
2.18m

Ground Clearance
274mm

Platform Capacity (SWL)
680kg

Max Drive Height
13.1m

Max. Wind Speed
12.5m/s

Max Drive Speed (stowed)
6.7km/h

Max Drive Speed (elevated)
0.8km/h

Raise/Lower Time
50/45 sec

Gradeability
50%

Max Stabilizer Leveling (front to rear)
7°

Max Stabilizer Leveling (side to side)
12?

Inside Turning Radius
2.03m

Outside Turning Radius
5.28m

Tyres
12 x 33 foam filled

Controls
Proportional joystick

Drive System
4 wheel drive

Power Source
Kubota diesel

Weight (without outriggers)
7,500kg

Weight (with outriggers)
8,147kg
