Snorkel SL26RT Sigma Boom Lift - Climb gradient upto 50 degrees!

The Snorkel SL26RT Speed Level is the original sigma boom lift. Climbing gradients up to 50% and featuring automatic self-levelling without outriggers, it offers superior stability. This Speed Level also features an extension deck for additional outreach. With superb ground clearance and powerful 4-wheel drive, the SL26RT can handle any jobsite.

STANDARD FEATURES
Automatic powered platform levelling
Powerful 4 wheel drive
Oscillating front axle
Roll-out deck extension
Descent alarm
High grip, all-terrain tires
Dual multi-disc brakes
Proportional controls
Flashing amber light
Power line to platform
Fold-down guardrails
All motion alarm
Hour meter & on-board diagnostics display
Horn
2 year parts & labour, 5 year structural warranty


Max Working Height
10.0 m

Max. Platform Height
8.0 m

Platform Size (stowed)
1.72m x 3.66m

Platform Size (extended)
1.72m x 4.6m

Extension Deck Length
0.91m

Overall Width
2.13m

Overall Length
3.79m

Stowed Height
2.6m

Min Height (guardrails folded)
1.7m

Chassis Ground Clearance
305mm

Axle Ground Clearance
195mm

Platform Capacity (SWL)
680kg

Max Drive Height
8.0m

Max. Wind Speed
12.5m/s

Max Drive Speed (stowed)
6.4km/h

Max Drive Speed (elevated)
0.8km/h

Raise/Lower Time
21/32 seconds

Gradeability
50%

Max Levelling (front to rear)
9°

Max Levelling (side to side)
13°

Inside Turning Radius
3.9m

Outside Turning Radius
5.64m

Tyres
26 x 12.00 – 12 foam filled

Controls
Proportional joystick

Drive System
4 wheel drive with hydraulic motors and flow dividers

Power Source
Kubota D-902 water-cooled diesel Tier 4 Final

Weight
3,500 kg
