The mini crane C4e from Hoeflon is a versatile and compact crane with a maximum lifting capacity of 2,350 kg. Its small size and light weight make it ideal for accessing hard-to-reach places like basements, upper floors, and rooftops. The crane is also easy to transport on a trailer, adding to its convenience.
Capacity : 2,350 kg
Maximum reach : 11.7m x 144kg
Maximum lifting height : 15.1m
Dimensions (L x W x H) : 2.8m x 0.75m x 1.82m
Dimensions with winch and jib : 3.04m x 0.75m x 1.95m
Total weight : 1,900 kg, up to 2,150 kg with options
Mast system : Cylinder and chain system
Boom angle : -5° to 83°
Swing range : 360°
Drive : Fully Electric
Incline angle : 20°
Ground pressure : 0.59 kg/cm²
Electric motor : 230 V
Adjustment : 30° adjustable
Tracks : Non-marking
Outriggers : Hydraulically extendable
Swing : Infinite
NarrowLifting started in the Netherlands under the name Hijsen in het Nauw B.V., with a mission to bring more flexibility to lifting operations. One of the founders, Appie, had worked as a freelance mechanic and often faced difficulties when renting mini cranes. Teaming up with Leendert, the co-founder of Hijsen in het Nauw, they decided to create a better solution. In 2014, they officially launched Hijsen in het Nauw and purchased their first mini crane, the Hoeflon C10, along with a Dolly for
