Spot Welding Machine

Smart Pressure Controlled Spot Welding Machine from Japan.
Available with variety of power supplies.
AC 30kVA single phase maximum current 10000amps 2.2kN pressure
Inverter 40kVA 3 phase maximum current 12000 amps 2.2kN pressure
Inverter 80kVA 3 phase maximum current 24000 amps 3.8kN pressure

Inverter models feature unique technology "High Speed Welding" patented.
- No Burn or Distortion (even zinc surfaces show no oxidization)
- Stronger Welds with no separation
- Direct Current
- Short Weld Time
- Large Output Current
- Controlled Waveform
- Energy Saving
- Touch Screen 3 step Control (Material Type - Material Thickness- Start Welding)
- External Finishing not required
- Aluminum Models. (up to 55000AMPS)
