Strautmann Verti-Mix Double Auger Self-Propelled Mixer

Self-propelled dual vertical-auger livestock-feed mixer with 20 cubic metre capacities for large scale dairy and livestock operations.

- The full-length chassis is fitted with parabolic suspension together with swivelling axle-rack for continuous 4-wheel contact with the ground
- Large hydraulic drum brakes are fitted front and rear
- 4-wheel drive
- Simple construction, minimal wear and low maintenance
- 20mm of base plate from ST 52-3 for long life
- 8mm thick container wall from ST 52-3 steel for long life
- 16mm thick augers from ST 52-3 steel for long life
- Air-conditioned
- Radio
- Fully adjustable seat
- 2m chopping unit cuts the fodder and rapidly transports it into mixing container via the 600mm wide elevator
- Spiral arrangement head guarantees extremely high loading capacity with minimal impact on the fodder structure
- Mineral feed funnel on conveyor
- Augers fitted with Vario vertical mixing augers for quick and exact mixing of fodder in all parts of the mixing container with less power requirement
- Additional scraper on auger for even and faster emptying
- Stainless steel wear strips
- Sabre shaped knives on the auger
- Adjustable counter cutters and knife position makes processing of whole round or square bales more effective
- Mixing overflow ring
- Front cross-conveyor with side shift and left or right-side feed-out
- Multi-function joystick controls all operating functions
- 10.4? touch screen displays all functions and status information
- ICS (integrated communication system) this terminal can display 3 systems (weighing device, machine info terminal and cameras)
- Integrated fault diagnostic system support
- Remote maintenance via modem
- Programmable weighing scales (without or with data transfer)
- Powered by a 6-cylinder John Deere motor turbocharged and intercooler
1374kW (178hp)
- Clean-Fix radiator ensures optimum performance of the cooling system when working with very dry and dusty fodder
- 4 Wheel hydrostatic drive (40km road speed)

N.B. Pricing and specifications subject to change without notice. Dealer delivery chargers apply. E&OE.
