MODEL
T-HAWK100-C
PRIME RATING
80/100 kW/kVA
ENGINE
CUMMINS 6BT5.9-G2
FUEL TANK
420 L
STANDBY RATING(AMPS)
153
STANDBY RATING(kW/kVA)
88/110
ALTERNATOR
STAMFORD UCI274C1
FUEL CONSUMPTION (L/h)
17.0
TECHNICAL DATA
Specifications
VIKING MODEL: T-HAWK100-C
VIKING MODEL: CUMMINS 6BT5.9-G2
ALTERNATOR: STAMFORD UCI274C1
STANDBY AMPS: 153A
STANDBY RATING(AMPS) (KW/KVA): 88kW/110kVA
PRIME RATING (KW/KVA): 80kW/100kVA
CONTINUOUS POWER (COP): 62kW/78kVA
DIMENSIONS AND WEIGHT
LENGTH (MM): 2,460MM
WIDTH (MM): 1,000MM
HEIGHT (MM): 1,733MM
WEIGHT (KG): 1,850KG
FUEL SYSTEM
FUEL TANK CAPACITY: 420L
PRIME FUEL CONSUMPTION 100%: 22.0L/H
PRIME FUEL CONSUMPTION 75%: 17.0L/H
PRIME FUEL CONSUMPTION 50%: 11.0L/H
