TOMAHAWK 15KVA KUBOTA GENERATOR

7 units on site in Brisbane warehouse

KUBOTA DIESEL ENGINE
110% BUNDED SKID BASE WITH FORK POCKETS
CENTRE LIFTING POINT
IP23 STAMFORD S0L1-P1 ALTERNATOR
50 DEGREE RADIATOR
ABB 4 POLE MANUAL CIRCUIT BREAKER
COMAP MRS16 CONTROL PANEL
ABB RD2 ADJUSTABLE RCD
BATTERY AND STARTER ISOLATOR
LOCKABLE ACCESS DOORS
1 X 32A OUTLET, 2 X 15A OUTLET
2.5MM STEEL HEAVY DUTY CANOPY




MODEL
T-HAWK15-K

PRIME RATING
12/15 kW/kVA

ENGINE
KUBOTA D1703-E2BG

FUEL TANK
100 L

STANDBY RATING(AMPS)
23A


STANDBY RATING(kW/kVA)
14/17


ALTERNATOR
STAMFORD S0L1-P1

FUEL CONSUMPTION (L/h)
3.7




TECHNICAL DATA


Specifications

VIKING MODEL: T-HAWK15-K

VIKING MODEL: KUBOTA D1703-E2BG

ALTERNATOR: STAMFORD S0L1-P1

STANDBY AMPS: 23A

STANDBY RATING(AMPS) (KW/KVA): 14kW/17kVA

PRIME RATING (KW/KVA): 12kW/15kVA

CONTINUOUS POWER (COP): 10kW/13kVA




DIMENSIONS AND WEIGHT


LENGTH (MM): 1,995MM

WIDTH (MM): 810MM

HEIGHT (MM): 1,465MM

WEIGHT (KG): 800KG




FUEL SYSTEM

FUEL TANK CAPACITY: 100L

PRIME FUEL CONSUMPTION 100%: 4.8L/H

PRIME FUEL CONSUMPTION 75%: 3.7L/H

PRIME FUEL CONSUMPTION 50%: 2.8L/H
