MODEL
T-HAWK300-C
PRIME RATING
240/300 kW/kVA
ENGINE
CUMMINS 6LTAA9.5-G1
FUEL TANK
1150 L
STANDBY RATING(AMPS)
459
STANDBY RATING(kW/kVA)
264/330
ALTERNATOR
STAMFORD S4L1S-D41
FUEL CONSUMPTION (L/h)
52.0
TECHNICAL DATA
Specifications
VIKING MODEL: T-HAWK300-C
VIKING MODEL: CUMMINS 6LTAA9.5-G1
ALTERNATOR: STAMFORD S4L1S-D41
STANDBY AMPS: 459A
STANDBY RATING(AMPS) (KW/KVA): 264kW/330kVA
PRIME RATING (KW/KVA): 240kW/300kVA
CONTINUOUS POWER (COP): 185kW/231kVA
DIMENSIONS AND WEIGHT
LENGTH (MM): 3,910MM
WIDTH (MM): 1,400MM
HEIGHT (MM): 2,425MM
WEIGHT (KG): 3,400KG
FUEL SYSTEM
FUEL TANK CAPACITY: 1150L
PRIME FUEL CONSUMPTION 100%: 70.0L/H
PRIME FUEL CONSUMPTION 75%: 52.0L/H
PRIME FUEL CONSUMPTION 50%: 35.0L/H
