MODEL
T-HAWK375-C
PRIME RATING
300/375 kW/kVA
ENGINE
CUMMINS NTAA855-G7
FUEL TANK
950 L
STANDBY RATING(AMPS)
574
STANDBY RATING(kW/kVA)
330/413
ALTERNATOR
STAMFORD S4L1D-F41
FUEL CONSUMPTION (L/h)
63.9
ECHNICAL DATA
Specifications
VIKING MODEL: T-HAWK375-C
VIKING MODEL: CUMMINS NTAA855-G7
ALTERNATOR: STAMFORD S4L1D-F41
STANDBY AMPS: 574A
STANDBY RATING(AMPS) (KW/KVA): 330kW/413kVA
PRIME RATING (KW/KVA): 300kW/375kVA
CONTINUOUS POWER (COP): 231kW/289kVA
DIMENSIONS AND WEIGHT
LENGTH (MM): 3,910MM
WIDTH (MM): 1,454MM
HEIGHT (MM): 2,310MM
WEIGHT (KG): 4,520KG
FUEL SYSTEM
FUEL TANK CAPACITY: 950L
PRIME FUEL CONSUMPTION 100%: 81.8L/H
PRIME FUEL CONSUMPTION 75%: 63.9L/H
PRIME FUEL CONSUMPTION 50%: 45L/H
