MODEL
T-HAWK80-C
PRIME RATING
64/80 kW/kVA
ENGINE
CUMMINS 4BTA3.9-G11
FUEL TANK
325 L
STANDBY RATING(AMPS)
123
STANDBY RATING(kW/kVA)
71/88
ALTERNATOR
STAMFORD UCI224G1
FUEL CONSUMPTION (L/h)
13.2
TECHNICAL DATA
Specifications
VIKING MODEL: T-HAWK80-C
VIKING MODEL: CUMMINS 4BTA3.9-G11
ALTERNATOR: STAMFORD UCI224G1
STANDBY AMPS: 123A
STANDBY RATING(AMPS) (KVA/KW): 88KVA/71KW
PRIME RATING (KVA/KW): 80VA/64KW
CONTINUOUS POWER (COP): 50kW/63kVA
DIMENSIONS AND WEIGHT
LENGTH (MM): 2,460MM
WIDTH (MM): 1,000MM
HEIGHT (MM): 1,733MM
WEIGHT (KG): 1,650KG
FUEL SYSTEM
FUEL TANK CAPACITY: 325L
PRIME FUEL CONSUMPTION 100%: 17.6L/H
PRIME FUEL CONSUMPTION 75%: 13.2L/H
PRIME FUEL CONSUMPTION 50%: 9.10L/H
